Product Description

Keychron V10 Max

The V10 Max is a QMK custom mechanical keyboard with 2.4 GHz wireless and Bluetooth 5.1 connection. It has a 75% layout and offers a gasket mount design, sound-absorbing foam, double-shot PBT keycaps, and more. The V10 Max is designed for a personalized experience and enhanced typing comfort.

All-around customizable keyboard

To build a fully customizable keyboard, we designed every component to be easily assembled so you can customize and adjust any or every parts the way you want.

2.4 GHz & Bluetooth Connection

Experience peak gaming performance on the fly with the 2.4 GHz wireless connection boasting a rapid 1000 Hz polling rate. For seamless multitasking across your computer, phone, and tablet, you can effortlessly connect the V10 Max via Bluetooth 5.1 to three devices.

Switch Layouts Between macOS & Windows

Built with the Mac users’ experience in mind while still retaining compatibility for Windows devices, the V10 Max comes with a system toggle and an additional set of customized keycaps for both Windows and macOS systems. You can now save two different layouts on the keyboard, one for each system.

An Epic Core Inside The Keyboard

A powerful ARM architecture MCU equipped with 256K Flash will provide more flexibility for developers. The polling rate is 1000 Hz right out of the box, which makes the latency hardly noticeable even in competitive games.

OSA Profile Double-shot PBT Keycaps

These double-shot PBT keycaps have a similar height to the OEM profile and has an SA-like shape. We named it the OSA (OEM spherical angled) keycap. The PBT keycaps will provide excellent oil resistance, enhance the type feel, and prevent the legends from fading out.

Program V10 Max with QMK & VIA

With full QMK and VIA support, you can easily program and remap each key on the keyboard. The open-source firmware means endless possibilities for keyboard layouts, shortcuts, backlight effects, even the knob, and more.

Gasket Mount Design

By adopting a gasket mount design along with a PC (Polycarbonate) plate, the V10 Max reduces acoustic resonance, delivering a softer and quieter typing experience with enhanced flexibility.

Dual Receivers

For a better 2.4 GHz wireless experience, the V10 Max comes with Type-C and Type-A receivers. Or save them in the keyboard magnetic storage slot.

Hot-swappable

Hot-swappable sockets are mounted on the PCB so you can install or change the switches without soldering. Fits 3-pin and 5-pin MX mechanical switches.

Screw-In PCB Stabilizers

We’ve integrated the PCB-mounted screw-in stabilizers for a smoother typing experience with less wobbliness on the big keys such as space bar and etc.

South-facing RGB LED Lights

South-facing RGB LED is designed to better illuminate the keyboard backlight from the typist’s angle with the premium non-shine-through PBT keycaps

Keychron V10 Max

Specifications

Width: 141.3 / 157.8 mm; Length: 386.7 mm; Front Height: 18.7 mm (without keycaps); Back Height: 27.2 mm (without keycaps); Feet Height: 3 mm; Angle: 3.5° / 6.7° / 9.3°; Weight: 958 ± 10 g (Fully Assembled Version); Body Material: ABS Plastic; Plate Material: PC; Keycaps: Double-shot PBT keycaps, not shine-through, OSA Profile (OEM height, SA shape); Switches: Gateron Jupiter Red; Hot-swappable: Yes. Compatible with most of the 3 pin & 5 pin MX mechanical switches such as Gateron, Cherry MX, Kailh, etc.; Stabilizer: Screw-in PCB stabs; Cable: Type-C cable + Type-A to Type-C adapter;

MCU: ARM Cortex-M4 32-bit STM32F402 (256KB Flash); Charging Port: USB Type-C; Operating Environment: -10℃ to 50℃; Polling Rate: 1000 Hz (2.4 GHz and wired) / 90 Hz (Bluetooth mode); Mount Style: Gasket Mount Design; Backlight: South-facing RGB LED; N-Key Rollover (NKRO): Yes for both wireless and wired modes; Compatible System: Windows/macOS/Linux; Bluetooth Version: 5.1; Bluetooth Device Name: Keychron V10 Max; Battery: 4000 mAh Rechargeable li-polymer battery; Charging Time: Around 5 hours; Wireless Working Time (Backlit off): Up to 225 hours (Lab test result may vary by actual use); Wireless Working Time (RGB): Up to 100 hours (Lowest brightness)

What’s in the box?

Keyboard: 1x Fully Assembled Keyboard Including; 1x Case; 1x PCB; 1x PC Plate; 1x Sound Absorbing Foam; 5 Sets x Stabilizers; 1 Set x Keycaps (PBT Double-shot); 1 Set x SwitchesCable: 1x Type-C to Type-C Cable; 1x Type-A to Type-C Adapter; 1x Extension Adapter for ReceiverReceiver: 1x Type-A 2.4GHz Receiver; 1x Type-C 2.4GHz ReceiverTools: 1x Keycap & Switch Puller; 1x Screwdriver; 1x Hex Key

All-around customizable keyboard. To build a fully customizable keyboard, we designed every component to be easily assembled so you can customize and adjust any or every parts the way you want
2.4 GHz & Bluetooth Connection. Experience peak gaming performance on the fly with the 2.4 GHz wireless connection boasting a rapid 1000 Hz polling rate. For seamless multitasking across your computer, phone, and tablet, you can effortlessly connect the V10 Max via Bluetooth 5.1 to three devices
Dual Receivers. For a better 2.4 GHz wireless experience, the V10 Max comes with Type-C and Type-A receivers. Enjoy the quick plug-and-play time. Or, put them away in the keyboard magnetic storage slot at the top right corner
An Epic Core Inside The Keyboard. A powerful ARM architecture MCU equipped with 256K Flash will provide more flexibility for developers. The polling rate is 1000 Hz right out of the box, which makes the latency hardly noticeable even in competitive games
OSA Profile Double-shot PBT Keycap. These double-shot PBT keycaps have a similar height to the OEM profile and has an SA-like shape. We named it the OSA (OEM spherical angled) keycap. The PBT keycaps will provide excellent oil resistance, enhance the type feel, and prevent the legends from fading out
