Product Description

New-product PTZ3E405-AI 4MP 5x Optical Zoom TiOC Wiz Network PTZ Camera

1/2.8″ 4Megapixel CMOS.5x optical zoom.Max. 25/30fps @ 4M.IR distance up to 50m (164.04 ft) (IR).Warm light illumination distance up to 30m (98.43 ft) (Warm light).SMD 3.0 ; Perimeter protection ; Face detection.Alarm: 1 in, 1 out; audio: 1 in, 1 out.Built-in Mic and Speaker for Two-way Talk.12 VDC/PoE power supply , IP66.Sound and light alarm (red and blue lights).

Specifications

Max. Resolution : 2560 (H) × 1440 (V) ROM / RAM :128 MB / 512 MB Electronic Shutter Speed : 1/1 s–1/30,000 s Min. Illumination : Color: 0.005 lux @ F1.6 ; B/W: 0.0005 lux @ F1.6 ; 0 lux (IR light on) Illumination Distance : 50 m (164.04 ft) (IR) ,30 m (98.43 ft) (Warm light) Illuminator On/Off Control : Zoom Prio; Manual; Auto; OffIlluminator Number : 2 (IR) ,2 (Warm light) ,1 (Red light) ,1 (Blue light)Lens Focal Length : 2.7 mm–13.5 mmMax. Aperture : F1.6–F3.0Field of View : H: 94.9°–30.1°;V: 51°–17.1°;D: 112.3°–34.6°Focus Control : Auto; semi-auto; manualClose Focus Distance : 1.5 m (4.92 ft)DORI Distance

Detect —————————– Observe ———————— Recognize ————- Identify

270m(885.83ft) ————- 106.6m(349.74ft) ————- 54m(177.17ft) ————- 27m(88.58ft)

PTZ

Pan/Tilt Range Pan: 0° to 355° ; Tilt: –15° to +90° Manual Control Speed Pan: 0.1°/s–36°/s ; Tilt: 0.1°/s–25.8°/s Preset Speed Pan: 35.7°/s; Tilt: 27.1°/ Preset 300 Power-off Memory Yes Idle Motion Preset IVS (Perimeter Protection) Tripwire; intrusion; crossing fence detection; loitering detection; abandoned/missing object; fast moving; parking detection; people gathering; vehicle/human alarm classification; linkage tracking Face Detection Supports face detection, snapshot, and face enhancement; Supports face cutout: Face, one-inch photo; Capturing strategies include real-time capturing and quality first. Auto Tracking Lite Yes SMD Yes Active Deterrence : Light Warning Red and blue light warning;; Flash duration: 5 s–30 s ; Flash frequency: high, medium, low Sound Warning Offers 21 types of sound alarms, and supports importing custom sound alarms. The sound alarm play times can be set between 1 to 10.

Video and Audio

Video Compression H.264H;H.264B;Smart ; H.265+; H.264;H.265;MJPEG(Sub Stream);Smart H.264+ Streaming Capability 3 streams Resolution 4M (2560 × 1440); 3M (2304 × 1296); 1080p (1920 × 1080); 1.3M (1280 × 960); 720p(1280 × 720); D1 (704 × 576); VGA (640 × 480); CIF (352 × 288) Video Frame Rate Main stream: 4M/3M/1080p/1.3M/720p @(1–25/30 fps) ; Sub stream 1: D1/CIF/VGA@ (1–25/30 fps) ; Sub stream 2: 720p @(1–25/30 fps) Bit Rate Control CBR/VBR Video Bit Rate H.264: 96 kbps–14848 kbps ; H.265: 38 kbps–8960 kbps Day/Nigh Auto (ICR)/Color/B/W Audio Compression G.711a; G.711Mu; G.726; MPEG2-Layer2; G722.1; PCM Audio Input 1 channel (LINE IN, bare wire,built-in mic (mutually exclusive)) Audio Output 1 channel (LINE OUT,bare wire;built-in speaker (mutually exclusive)) Alarm Linkage Capture; recording; send email; preset; alarm digital input; audio; warning light Alarm Even Motion/tampering detection; audio detection; network disconnection detection; IP conflict detection; memory card state detection; memory space detection. Alarm I/O 1/1 Audio I/O 1/1

Network

Network Port RJ-45 (10/100 Base-T) Network Protoco FTP;RTMP;IPv6;Bonjour;IPv4;DNS;RTCP;PPPoE;NTP;RT P;802.1x;HTTPS;SNMP;TCP/IP;DDNS;UPnP;NFS;ICMP;U DP;IGMP;SMB;HTTP;SSL;DHCP;SMTP;Qos;RTSP;ARP Streaming Method Unicast/Multicast User/Host 20 (total bandwidth: 64 M) Storage FTP/SFTP; Micro SD card (512 GB); NAS Browser IE 9 and later versions ; Chrome 41 and later versions ; Firefox 50 and later versions ; Safari 10 and later versions Management Software DMSS;DSS Pro Mobile Client iOS;Android Power Supply 12 VDC, 2 A ± 10% ; PoE+ (802.3at) Power Consumption Basic: 4.5 W ; Max.: 15 W (illuminator + PTZ + speaker + heating glass) Operating Temperature –30 °C to +60 °C (–22 °F to +140 °F) Operating Humidity ≤95% Protection IP66, TVS 6000 V lightning proof; surge protection; voltage transient protection Product Dimensions 165.5 mm × 140 mm × 271.6 mm (6.52″ × 5.51″ × 10.69″) (L × W × H) Net Weight 1.5 kg (3.31 lb) Gross Weight 2.1 kg (4.63 lb)

Installation

Installation Types

Wall MountCeiling MountBase Bracket Includes

Optional Accessories（Bracket needs to be purchased separately）：

PFA121 Water-Proof Junction BoxPFA152-E Pole Mount Bracket

Packing List

Network Camera × 1Mounting Bracket × 1Installation Package × 1

SD Card Slot and Hard Reset Button

Do not keep the lower cover open for a long time in humid environment, in case of water mist risk.

SD card slot is available on select models.Disconnect the power from the device before installing the SD card.Press the reset button for 10 seconds to reset the device.Please do this when device ic powered on.

Dimensions (mm[inch])

Product Dimensions 165.5 mm × 140 mm × 271.6 mm (6.52″ × 5.51″ ×10.69″) (L × W × H)Net Weight 1.5 kg (3.31 lb)Gross Weight 2.1 kg (4.63 lb)

1/2.8″ 4Megapixel CMOS, 2.7 mm–13.5 mm lens, 5x optical zoom.
Max. 25/30fps@4M ,H.264H;H.264B;Smart H.265+; H.264;H.265;MJPEG(Sub Stream);Smart H.264+ .
Sound and light alarm (red and blue lights); Warm light illumination distance up to 30 m (98.43 ft) (Warm light) ; IR distance up to 50 m (164.04 ft) (IR).
Smart AI :SMD 3.0,Perimeter protection,Face detection,Auto Tracking Lite
Alarm: 1 in, 1 out; audio: 1 in, 1 out; Built-in Mic and Speaker for Two-way Talk.
